Vista -VM600 Series Electromagnetic Lock

(No reviews yet) Write a Review
SKU:
VM600
UPC:
VM300 Electromagnetic lock
  • 600 lbs. holding force maglock with field selectable dual voltage. Suitable for interior doors where physical assault is not expected. Indoor use only.
  • Armature plate screws into bracket ◾ Includes rubber gasket and steel tension plate ◾ Will allow up to 9/16" thick glass
  • Used to mount lock on the secure side of a door that swings into a secured area ◾ Fully adjustable bracket provides additional lateral movement to address the most challenging doors ◾ Allows for precision adjustments
  • Used when a blade stop requires the Maglock to be lowered as with most aluminum frame glass doors ◾ Comes pre-drilled (lock specific) with countersinks for the mounting bolts and wire
  • 90 degree angle brackets ◾ Extends narrow headers to permit proper mounting ◾ 2nd standard mounting bracket provided for additional strength
$186.50

Description



SECURITRON VISTA VM600 SERIES ELECTROMAGNETIC LOCK

600 lbs. Holding Force Magnalock

600 lbs. holding force maglock with field selectable dual voltage. Suitable for interior doors where physical assault is not expected. Indoor use only.

Features and Benefits

  • Individually tested for holding force
  • Easy Mount Adjustable Bracket
  • Instant release (no residual magnetism)
  • Optional Bond Sensor and Door Position Switch available
  • Wire Access Chamber with Plug-In connectors
  • Dual voltage 12/24VDC
  • Brushed Aluminum Finish
  • UL Listed

Product Packaging



Specification Data

Holding Force: 600 lbs [272 kg] Voltage: 12 or 24VDC (field selectable) Current Draw: 520mA at 12VDC, 260mA at 24VDC Operating Temperature: +32 to +110F [0 to +43C] 9-3/8" [238mm] x 1-57/64" [48mm] x 1-3/64" [27mm] Shipping Weight: 5 lbs.
