Hager 9630 Heavy Duty Pocket Door Kit

Hager 9630 Heavy Duty Pocket Door Kit

• For doors 1-3/8"- 1-3/4" (35mm - 44 mm) thick, up to 3'0" (914 mm) wide and 6'8" (2032 mm) high
• For door weighing up to 125 lbs (56.699 kg) - 9601 aluminum jump proof box track with quick release rollers
• Pre-assembled header assembly goes up quickly
• Easy door installation and removal for painting and repair
• 2 pair of wood split studs with wood inserts
• size 3/4" (19 mm) x 1-5/8" (26 mm) length relative to height
• steel encased for rigidity and to prevent fastener penetration into the pocket
• Track header unit attaches to rough framing at both ends
• Split studs can be nailed or screwed to track header
• Conform to ANSI A156 14/ Type: D8671, D8701
• For Bi-Parting Doors use Hager Double Pocket Door Kit 9639 (sold separately)
• Joins 2 pocket door frames to make one large doorway. Rough opening width changes to 4 times one door width.
• Length: 80" (2032 mm).
