Falcon T561CP 6 DANE - Grade 1 Classroom Lever Lockset

Falcon T561 DANE- Grade 1 Classroom Lever Lockset

The T-Series is now stronger than ever and lever sag has been virtually eliminated. This adaptable lock is well suited to either new construction or retrofit use in buildings as varied as business/office, retail, institutional and government/military.

The classroom function has the outside lever locked when a key from the outside locks it, and is always free from the inside making it panic proof. When you need to replace an existing notched-style lock and get up to code on ADA accessibility the Falcon RU Series is a perfect fit. Designed specifically for retrofitting older and historical buildings, this unique lock combines old-fashioned styling with modern strength, security and convenience. Falcon RU Series locks have an interchangeable core that can be removed for quick, easy re-keying. Falcon's interchangeable cores are compatible with SFIC products from other manufacturers. And they’re backed by one of the best names in the business.

For over 40 years Falcon Lock has been manufacturing the industry's most trusted lock hardware. Their reputation and commitment to providing a high quality product at a reasonable price with timely delivery has been rewriting the standard in their industry. Falcon has one of the most extensive lines available on the market today, with a choice of functions and applications to surpass even the most demanding commercial requirements and usage situations.

Product Features & Technical Specifications:

• ANSI/BHMA: Meets ANSI/BHMA A156.2, Series 4000, Grade 1.
• Door Thickness: 1-3/4"to 2-1/8"standard. Thin door adapter kit (A30775-000-00) available for doors thinner than 1-3/4". Thicker door locks also vailable, consult factory.
• Backset: 2-3/4" standard. 2-3/8" and 5" also available.
• Handing: Locks are non-handed.
• Cylinders: Drilled with 6 pin chambers, pinned in 5.
• Pinning in 6 chambers vailable when specified. 7 pin cylinders also vailable.
• Cylinder assemblies removable to rekey.
• Also vailable with 6 or 7 pin interchangeable core cylinders.
• Cylinder housings and plugs machined from solid brass. Springs are phosphor bronze.
• Two nickel silver keys furnished standard.
• Keyways: “G” keyway standard on standard cylinders. “A” keyway standard on I/C core cylinders. Also available with some optional keyways. Please contact us if you need additional ordering information.
• Latches: 1/2" bolt projection, UL listed with latch faceplates 2-1/4" x 1-1/8" with square corners standard. 3/4" projection, UL listed latch with 2-3/4" backset also vailable. Adjustable front standard.
• Strikes: 4-7/8" x 1-1/4" ANSI strike with curved lip to meet ANSI A115. 2 door frame preparation standard.
• UL: 3 hour A label.
• Deadlocking latch bolt by levers. Outside lever is locked by key in outside lever. Inside lever is always free.
